Automatic 8 Heads Fresh Cream Piston Volumetric Bottle & Liquid
Filling Machine
Introduce
Automatic filling machine capacity can be customized to suit
production speed. This bottling filling machine can be used for
bottling juices, oils filling line, honey, food products, pharmacy
syrups, foamy liquids filling line, free flowing low to medium
viscous liquids. Automatic filling machines suitable to
free-flowing liquids like oil, beverage, lotion . It can be applied
to a wide range of industries including food and beverages, with
high capacity, accuracy and stability, quick and easy changeover to
save operation time, equipped with anti-dust and hygiene concern
housing for option.
Advantage
1. Built with anti-dust housing, hygiene concerning.
2. Filling nozzles can be customized for quantity and filling way
to meet production requirement.
3. Advanced valves prevent liquid from dripping down.
4. Drip tray setting, surplus liquid backflow, no waste.
5. Adopted servo motor and gear pump, filling precisely and quick.
6. User-friendly system, simple-to-use.
7. No bottle, no fill sensor.
8. Color touch screen and PLC controlled.
9. Program recipe storage for simple and quick changeovers.
10. Precise sensor detected, no bottle, no fill.
11. Start, emergency stop and speed controller configuration.
12. Multiple filling and conveying speeds for accurate control of
production.
13. Automatic pneumatic gates for bottle entry and exit.
14. Sturdy conveyor.
15. Conveyor guide rail can be adjusted to accommodate any size of
bottles.
16. Built with mobility castors enable easy movement.
17. Heavy-duty steel, easy-to-maintain.
18. Compliance with GMP standard, made of SUS304 stainless steel
and anodized aluminum.
Main technical parameters
| No. | Item | Performance |
| 01 | Requested speed | 100bpm |
| 02 | Filling volume | 500ml(could be customized based on requirements) |
| 03 | Number of filling heads | 16 |
| 05 | Accuracy | Up to ±1% |
| 06 | Machine dimension(L*W*H) | 2400mm*1350mm*2500mm |
| 07 | Power | 5KW |
| 08 | Power supply | AC 380V,50Hz;or AC 220V,50Hz (Customized) |
| 09 | Air operated source | 0.4-0.6Mpa clean and stable compressed air |
| 10 | weight | About2000kg |
Major technical components
| No. | NAME | BRAND |
| 01 | Frequency converter | Schneider |
| 02 | Intermediate Relay | Panasonic |
| 03 | PLC | Siemens |
| 04 | Touch Screen | Siemens |
| 05 | Breaker | Schneider |
| 06 | Servo | Panasonic |
| 07 | Photosensor | SICK |
| 08 | Airpressure-Switch | Airtac |
FAQ
1---If have stock machine?
For semi automatice machine, we all have stock. Can ship within 7
working days. For automatic machine, all have no stock. Automatic
machines are customized made according to bottles and caps. It need
place the order, then manufacture.
2---How long time to make?
For single machine, it takes from 10~30 working days. For whole
filling line, it takes from 40~60 working days.
3---Ship from which port?
If by air, it is from Shanghai International Airport. If by sea, it
is from Shanghai or Ningbo. Other seaport of China is also
accepted.
4---The payment?
By TT. 50% in advance as downpayment , 50% balance before shipping.
-If can visit factory to check machines firstly, then place order?
Sure! Welcome to visit us !
After-sales Service:
(1) Under stable voltage, the machines' quality that we sold will
be guaranteed for 1 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and
debugging machines. Engineer's round-trip tickets, accommodation,
and your side traveling fee will be charged by you. Engineer's
salary will be USD60.00/day/person.
We can also supply training process for your engineers who come to
china, so you can fit and debug machines by yourself.
