    Energy Saving Aerosol Filling Line With Liquid Filling Machine And Aerosol Crimping Machine

    Ask Lasest Price
    Brand Name : STRPACK
    Certification : ISO,CE
    Model Number : STR
    Price : Price Negotiable
    Delivery Time : 3-50 Working Days
    Payment Terms : TT/LC
    Supply Ability : 1000 SET
    • Product Details
    • Company Profile

    Energy Saving Aerosol Filling Line With Liquid Filling Machine And Aerosol Crimping Machine

    Aerosol Filling Line With Liquid Filling Machine,Crimping & Gassing Machine, Can Weight Checking Machine Water-bath Leakage Tester




    Application
    Suitable for Aerosol filling, capping, labeling and cartoning.
    Air Pressure: 0.4~0.6MPa
    Capacity: 2,000-5,000 BPH
    Filling Volume: 0~1kg
    Required Operator: 3-4 workers
    Equipment Noise: ≤80dB


    Also suitable for
    Food: Jam, Sauce, Paste, Honey, Chili Sauce, Ketchup, Edible oil, Olive oil, Salad Dressing, Salsa, Barbecue Sauce.

    Pharmaceutical: Liquid vitamins, E-liquid, Peroxide, Syrup, Eye drops, Fish oil, Nasal spray, Alcohol, Lotion.

    Daily Chemical: Liquid soap, Cleaning Chemical, Laundry liquid, Toilet Cleaning Agent, Dish Detergent, Detergent, Cleaning Fluid, Bleach, Disinfectant.

    Personal Care: Shampoo, Hair Care, Hair Gel, Lotion, Lip Balm, Nail Polish, Shower Gel, Hand Soap, Hand Cream, Body Lotion, Cream, Perfume.

    Agrochemical: Pesticide, Fertilizer, Herbicide, Paraquat, Imazethapyr, Bactericide, Rodenticide.
    Chemical: Corrosive Product, Fuel, Lubricating oil, Antifreeze, Brake Fluid, Paint, Coating, Glue, Adhesive, Additive.


    Automatic Aerosol Filling Machine

    AF-50A automatic aerosol filling machine consists of automatic can feeding machine, automatic liquid product filling machine, automatic crimping & gassing machine and conveyor. It could complete the job of automatic can feeding, blowing, liquid product filling, crimping and gassing. The working speed output rate could reach 30-70 cans per minute.

    Automatic aerosol filling machine is full air driven except the conveyor. The main pneumatic parts are from SMC Japan. It’s a set of effective, reliable, easy operation and easy maintenance machine.

    The filling part of Automatic aerosol filling machine could be controlled independently, no can no filling. Guide rails for crimping so that the crimper would stop working if the sealing is not qualified. Guide rails for gassing part as well, accurate, effective and less consumption.

    Automatic aerosol filling machine could work with automatic valve placing machine, automatic weight checking machine for aerosol cans, automatic water bath leakage detection machine, automatic actuator placing machine, automatic cap presser and ink jet printer to complete a full automatic aerosol production line.

    ModelAF-50A
    Filling capacity15-750ml (can be customized)
    Filling accuracy≤±1%
    Propellant filling capacity15-750ml (can be customized)
    Propellant filling accuracy≤±1%
    Capping accuracy≤1%
    Production capacity2400-3600 cans/hr
    Air source0.6Mpa-1Mpa clean and stable air source
    Max air consumption3 M³/min
    Can Height80~330
    Can DiameterΦ35~Φ80
    Weightabout 2000kg
    Dimension(L×W×H)12000×1500×2100



    Bottle feeding machine, Full automatic bottle unscrambler
    Bottle rinsing machine-air rinser, Bottle rinsing machine-wet rinser
    Servo type piston filling machine, Gravity liquid filling machine, Corrosive liquid filling machine
    Linear Capping machine, Rotary Capping machine, Cap pressing machine, Crimping machine
    Induction sealer
    Round bottle labeling machine, Front & back labeling machine, Sleeve labeling machine
    Ink jet printer
    Shrink packing machine
    Carton erector
    Carton packaging machine
    Carton sealing machine
    Palletizer



    FAQ:
    1---Any machine in stock?
    For semi automatice machine, we have some in stock. It can ship within 7-10 working days. For automatic machine, all have no stock. Automatic machines are custom-made according to your bottles and caps.

    2---What is the lead time?
    For single machine, it takes from 20~35 working days. For whole filling line, it takes from 50~60 working days. (from the day we have the downpayment and sample bottle and caps)

    3---Can you help the shipment? Ship from which port?
    Yes, we can help to the shipment, just tell us the name of sea port in your side. If by air, it is from Shanghai International Airport. If by sea, it is from Shanghai or Ningbo. And other seaport of China are accepted.

    4---The payment?
    By TT. 50% in advance as downpayment , 50% balance before shipping.
    5---can we visit factory to check machines firstly, then place order?
    Sure, welcome to visit us!

    After-sales Service:
    (1) Under stable voltage, the machines' quality that we sold will be guaranteed for 12months
    (2) Long time technology will be supplied.
    (3) We can send our engineer to your side for installing and debugging machines and training your people. Engineer's round-trip tickets, accommodation, daily allowance USD80.00/day/person, and your side traveling fee will be charged by you.
    We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.

    About Us
    --Focusing on Development, Packaging Industry Leader
    --Keeping on Recruiting Talents and Innovation
    --Advanced equipment, Guaranteed quality
