    Pesticide and Chemical Fertilizer Filling Machine With Anti-corrosive Gravity Filling Machine,Linear Capping Machine

    Ask Lasest Price
    Brand Name : STRPACK
    Certification : ISO,CE
    Model Number : STR
    Price : Price Negotiable
    Delivery Time : 3-50 Working Days
    Payment Terms : TT/LC
    Supply Ability : 1000 SET
    • Product Details
    • Company Profile

    Pesticide and Chemical Fertilizer Filling Machine With Anti-corrosive Gravity Filling Machine,Linear Capping Machine

    Pesticide and Chemical Fertilizer Filling Machine With Anti-corrosive Gravity Filling Machine,Linear Capping Machine



    Automatic Anti-corrosive Gravity Filling Machine

    Brief Introduction

    This is gravity type filling machine, it is made for filling corrosive liquid such as bleach, acid liquid, 84 disinfectant, gel water, toilet cleaner etc.

    All product contact parts is made with non-metal material to avoid the corrosion.
    PVC filling head ;valve; feeding pipes., Nylon bottle fixer , PE filling tank

    With PLC control and Touch screen , machine is stable and convenient for operation.

    Linear structure which is suitable to run several different size bottles.

    Main Parameter:

    ModelUnitSFL
    Nozzle NumberPCS8121620
    Filling volumeMl20-5000
    Production capacityBottle/h720-25001200-30001800-40002000-5000
    Quantitative error%20-1000ml:≤±2% , 1000-5000ml:≤±1%
    Source voltageVThree-phase four-wire system AC220V 380V ±10%
    Consumed powerKW0.50.50.750.75
    Gas supply pressureMPA0.4-0.6
    Air consumptionM3/min0.811.21.2

    Aautomatic Linear Capping Machine(Screw Cap)

    Brief Introduction

    This automatic capping machine is used for closing screw caps, it is made up by 3 parts: Cap feeding system, cap loading system and cap closing system.
    Linear structure which is flexible to run different size bottles without change parts.
    Cap feeding system will be made according to cap sample( by Vibrating bowl or Cap elevator) .
    It is also ok for closing pump cap, trigger cap (Cap feeding and loading have to be done by hand).

    PLC control system and touch screen is available for your option.

    Simple system and easy operation , the machine is widely used on foodstuff,pharmacy, cosmetic, daily chemical, fertilizer and chemical industries.

    Parameter:

    No.
    Model
    SX-A
    1
    Speed
    0-100pcs/Min
    2
    Cap Type
    Screw cap
    3
    Bottle Diameter
    35-90mm
    4
    Bottle Height
    50-250mm
    5
    Cap Diameter
    20-50mm
    6
    Power
    2.2KW
    7
    Air Pressure
    0.6-0.8Mpa
    8
    Voltage
    220V 50/60HZ
    9
    Weight
    600KG
    10
    Dimension
    2000mm × 850mm × 2050mm


    FAQ:

    1---Any machine in stock?

    For semi automatice machine, we have some in stock. It can ship within 7-10 working days. For automatic machine, all have no stock. Automatic machines are custom-made according to your bottles and caps.


    2---What is the lead time?
    For single machine, it takes from 20~35 working days. For whole filling line, it takes from 50~60 working days. (from the day we have the downpayment and sample bottle and caps)


    3---Can you help the shipment? Ship from which port?
    Yes, we can help to the shipment, just tell us the name of sea port in your side. If by air, it is from Shanghai International Airport. If by sea, it is from Shanghai or Ningbo. And other seaport of China are accepted.


    4---The payment?
    By TT. 50% in advance as downpayment , 50% balance before shipping.

    5---can we visit factory to check machines firstly, then place order?
    Sure, welcome to visit us!



    After-sales Service:
    (1) Under stable voltage, the machines' quality that we sold will be guaranteed for 12months
    (2) Long time technology will be supplied.
    (3) We can send our engineer to your side for installing and debugging machines and training your people. Engineer's round-trip tickets, accommodation, daily allowance USD80.00/day/person, and your side traveling fee will be charged by you.
    We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
