Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle

ZhongLi Packaging Machinery Co.,Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle from wholesalers

    Buy cheap Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle from wholesalers
    • Buy cheap Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle from wholesalers
    • Buy cheap Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle from wholesalers
    • Buy cheap Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle from wholesalers
    • Buy cheap Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle from wholesalers

    Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle

    Ask Lasest Price
    Brand Name : STRPACK
    Certification : ISO,CE
    Model Number : STR
    Price : Price Negotiable
    Delivery Time : 3-50 Working Days
    Payment Terms : TT/LC
    Supply Ability : 1000 SET
    • Product Details
    • Company Profile

    Low Noise Bottle Packing Machine Line Plastic Bottle Unscrambler For Food / Medicine Bottle

    Automatic Bottle Unscrambler

    Packaging & Delivery

    Packaging Details : In Wooden Case, Standard Exporting Packing
    Delivery Time : 22Day

    Automatic Bottle Unscrambling Machine is suitable for plastic PE/PP/PET bottles. It is widely used for food, medicine bottle, jar etc.

    Main Features

    1. This machine is electromechanical, working stable and reliable, low noise, convenience in operation and maintenance. The touch screen is in Chinese and English language, and machine is control by PLC system. It can count, set working parameter, display and can be set freely in the range of parameters.
    2. It is equipped with quantity control system and overload protection device. The noise in under 70dB.
    3. It’s made of 304 stainless steel, easy to clean and disinfection, meeting GMP requirements.
    4. The machine will upright the bottles and has two stepless speed control motors. One is controlling the rotary rolling speed, the other one is controlling the conveying speed.
    5. A bowing device is installed on the outlet, blow out inverted bottles back into unscrambler.


    Number
    ITEM
    PARAMETER
    1
    speed
    no more than 150 bottles/min (adjustable speed)
    2
    bottle size
    within 350ml
    3
    voltage/frequency
    220v/50-60hz
    4
    air pressure
    0.5MPa
    5
    power
    0.5kw
    6
    specification
    1000X1500X1200 or 1000X1200X1260 mm
    7
    Weight
    150kg


    Number
    Description
    Model
    Brand
    1
    frequency converter
    SINAMICS V20
    Siemens
    2
    interface
    SMART 700 IE
    Siemens
    3
    switch power
    DVP-PS02
    Delta
    4
    relay
    AHN22324N
    Panasonic
    5
    photoelectric switch
    E3Z-D61
    OMRON
    6
    air switch
    iC65N
    Schneider
    7
    emergency stop button
    ZB2-BS54C
    Schneider
    8
    motor
    5RK90GU-SF
    Maili
    FAQ
    1---If have stock machine?
    For semi automatice machine, we all have stock. Can ship within 7 working days. For automatic machine, all have no stock. Automatic machines are customized made according to bottles and caps. It need place the order, then manufacture.
    2---How long time to make?
    For single machine, it takes from 10~30 working days. For whole filling line, it takes from 40~60 working days.
    3---Ship from which port?
    If by air, it is from Shanghai International Airport. If by sea, it is from Shanghai or Ningbo. Other seaport of China is also accepted.
    4---The payment?
    By TT. 50% in advance as downpayment , 50% balance before shipping.
    -If can visit factory to check machines firstly, then place order?
    Sure! Welcome to visit us !

    After-sales Service:
    (1) Under stable voltage, the machines' quality that we sold will be guaranteed for 1 year
    (2) Long time technology will be supplied.
    (3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you. Engineer's salary will be USD60.00/day/person.
    We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
